Flat cap nut DIN917

Material：
Carbon steel, Stainless steel
Size：
M5-M12
Surface Treatment：
Galvanizing
Enquiry
Flat cap nut DIN917
Flat cap nut DIN917
Flat cap nut DIN917
Flat cap nut DIN917

Flat cap nut DIN917

Dimensions: mm

Thread size
d
M4 M5 M6 M8 M10 M12 (M14) M16 (M18) M20
P Pitch (coarse thread) Series 1
Pitch (fine thread) Series 2
Series 3
and Maximum
Minimum
dw Minimum
and Minimum
x Maximum Series 1
Series 2
Series 3
g Maximum Series 1
Series 2
Series 3
h Maximum value = nominal
Minimum
r ≈
s Maximum value = nominal
Minimum
t Maximum
Minimum
In Minimum
Thousand pieces weight (steel) ≈ kg
0.7 0.8 1 1.25 1.5 1.75 2 2 2.5 2.5
/ / / 1 1.25 1.5 1.5 1.5 2 2
/ / / / 1 1.25 / / 1.5 1.5
4.6 5.75 6.75 8.75 10.8 13 15.1 17.3 19.5 21.6
4 5 6 8 10 12 14 16 18 20
5.9 6.9 8.9 11.6 14.6 16.6 19.6 22.5 24.9 27.7
7.66 8.79 11.05 14.38 17.77 20.03 23.35 26.75 29.56 32.95
1.05 1.2 1.5 1.87 2.25 3.5 4 4 5 5
/ / / 1.5 1.87 3 3 3 4 4
/ / / / 1.5 2.5 / / 3 3
2.75 3 3.7 4.9 5.6 6.4 7.3 7.3 9.3 9.3
/ / / 3.7 4.9 5.6 5.6 5.6 7.3 7.3
/ / / / 3.7 4.9 - - 5.6 5.6
5.5 7 9 12 14 16 18 20 22 25
5.2 6.64 8.64 11.57 13.57 15.57 17.57 19.48 21.48 24.48
8 10 12 15 20 25 28 30 32 35
7 8 10 13 16 18 21 24 27 30
6.78 7.78 9.78 12.73 15.73 17.73 20.67 23.67 26.16 29.16
4.64 5.44 7.29 9.79 11.35 13.85 15.35 17.35 19.42 21.42
4.16 4.96 6.71 9.21 10.65 13.15 14.65 16.65 18.58 20.58
1 1 1.5 2 2 2 2 2 2 2.5
1.3 2.2 4 9.5 15.6 23 35 46.5 70 94
Thread size
d
(M22) M24 (M27) M30 M36 M42 M48 (M56) (M64) (M72)
P Pitch (coarse thread) Series 1
Pitch (fine thread) Series 2
Series 3
and Maximum
Minimum
dw Minimum
and Minimum
x Maximum Series 1
Series 2
Series 3
g Maximum Series 1
Series 2
Series 3
h Maximum value = nominal
Minimum
r ≈
s Maximum value = nominal
Minimum
t Maximum
Minimum
In Minimum
Thousand pieces weight (steel) ≈ kg
2.5 3 3 3.5 4 4.5 5 5.5 6 /
2 2 2 2 3 3 3 4 4 4
1.5 / / / / / / / / /
23.7 25.9 29.1 32.4 38.9 45.4 51.8 61 69.1 77.8
22 24 27 30 36 42 48 56 64 72
31.4 33.3 38 42.8 51.1 60 69.5 78.7 88.2 97.7
37.29 39.55 45.2 50.85 60.79 72.02 82.6 93.56 104.86 116.16
5 6 6 7 8 9 10 11 12 12
4 4 4 4 6 6 6 8 8 8
3 / / / / / / / / /
9.3 10.7 10.7 12.7 14 16 18.5 20 21 21
7.3 7.3 7.3 7.3 10.7 10.7 10.7 14 14 14
5.6 - - - - / / / / /
28 30 32 34 44 52 58 68 75 85
27.48 29.48 31.38 33.38 43.38 51.26 57.26 67.26 74.26 84.13
35 40 50 60 70 80 90 110 130 130
34 36 41 46 55 65 75 85 95 105
33 35 40 45 53.8 63.1 73.1 82.8 92.8 102.8
22.42 24.42 26.42 28.42 36.5 42.5 48.5 56.6 62.6 67.6
21.58 23.58 25.58 27.58 35.5 41.5 47.5 55.4 61.4 66.4
3 3 3 3 4 4 4 5 5 5
119 157 229 310 577 958 1410 2100 2840 3910
